| Product Series | W.Fans Series | ||||||||
|---|---|---|---|---|---|---|---|---|---|
| Model | W26 | W24 | W22 | W20 | W18 | W16 | W14 | W12 | WS10 |
| Specification/ Diameter(m) | 8 | 7.3 | 6.7 | 6.1 | 5.5 | 4.9 | 4.2 | 3.6 | 3.1 |
| Speed (rpm) | 10-45 | 10-55 | 10-60 | 10-60 | 10-70 | 10-75 | 10-80 | 10-90 | 10-100 |
| Full-load air volume(m³/min) | 17676 | 16130 | 14804 | 13800 | 12152 | 10826 | 9280 | 7954 | 6849 |
| Coverage area(m²) | 2462 | 2123 | 1809 | 1520 | 1256 | 1017 | 804 | 615 | 452 |
| Rated power rate(kw) | 1.5 | 1.1 | 0.75 | 0.4 | |||||
| Average consumption(kwh) | ≤1.2 | ≤1.0 | ≤0.7 | ≤0.4 | |||||
| Noise(dB) | ≤38 | ||||||||
| Power supply (V) | 380V/220S | ||||||||
| Full-load current(A) | 2.8（380V）/4.6（220V） | 2.6（380V）/3.0（220V） | 2.5 | 2.0 | |||||
| Weight(kg) | 108 | 92 | 90 | 73 | 63 | 60 | 47 | 42 | 39 |
