It started with a Big idea; that high-volume, low-speed (HVLS) airflow was the key to making spaces more comfortable and efficient. The HVLS Fan Company combined quality design with size, and it didn't take long for people to notice and to rebrand the company as an upstart innovator in HVLS technology.
From the leadership in R&D, to the workmanship on the factory floor, each and every one of us takes pride in knowing that the fans we make will one day make a difference with cool and comforting airflow that keeps businesses bustling and homeowners happy.
It started with a big idea in engineering: that the combination of size and quality design could fundamentally change what ceiling fans could accomplish. That high-volume, low-speed (HVLS) airflow—an entirely new concept—was the key to making spaces more comfortable and efficient. Because the “HVLS Fan Company” thought big, it didn’t take long for people to notice the impact our products had on facilities or for them to rebrand the company the way they saw us: as an upstart innovator in HVLS fans. Proven by our products’ performance, what started as a big idea became a workplace revolution and is now best practice for designers, managers, and business owners across every imaginable industry and application. Go to work, hit the gym, or enjoy a night on the town and chances are you’ll see our ceiling fans keeping the peace smoothly and silently. From factories to homes and everywhere in between, these fans deliver comfort, style, and energy savings that make life and work more enjoyable.
The fan adopts permanent magnet brushless motor, which has high power efficiency and power factor. Fully enclosed structure, no transmission gear wear and transmission gear noise, no lubrication, maintenance free. Permanent magnet motor is built-in high insulation enamel coil, super magnetic steel body, high temperature resistance bearing. Super torque, large load operation, good temperature rise, smooth operation, very quiet. High power density, compact size and light weight.
Apply the vector variable frequency control methods with the smart technology. Adopts a renowned inverter brand. Well-adapted power environment. Power supply phase failure protection, over voltage protection, over current protection, overload protection, output phase loss protection, output ground protection, over temperature protection, signal disconnection.
The surface of blades are treated with natural color antisepsis and oxidation, and then powder spraying was carried out. By curing at a high temperature of nearly 200 degree, a film of 70 ± 5 um is formed on the surface of fan blade, which is smooth, delicate, beautiful and easy to clean. Color of blade can be customized according to requirement.
| Customized support | OEM, ODM |
| Blade Material | Aluminum Alloy |
| Mounting | Ceiling Fan |
| Power | 0.5KW |
| Voltage | 110V/220V |
| Warranty | 3 years |
| No.s of Blade | 6PCS |
| Fan Diameter | 4.2M/14FT |
| Frequency | 50HZ/60HZ |
| Weight | 45kg |
| Height | 1500mm |
| RPM(MIN/MAX) | 0-63RPM |
| Package | Wooden Cases |
One fan is to be packed into two sea-worthy wooden cases:
1) Blade Case: 20 * 20 * 121 CM
2) Motor Case: 44 * 30 * 36 CM
If you have any needs, welcome to send us your inquiry. We'll do our best to make all your needs satisfied!!!
