| Model | HDS-3 | HDS-3.7 | HDS-4.3 | HDS-5 | HDS-5.5 | HDS-6.1 | HDS-6.7 | HDS-7.3 | HDS-6.7 | HDS-7.3 |
|---|---|---|---|---|---|---|---|---|---|---|
| diameter(m) | 3 | 3.7 | 4.3 | 5 | 5.5 | 6.1 | 6.7 | 7.3 | 6.7 | 7.3 |
| diameter(ft) | 10 | 12 | 14 | 16 | 18 | 20 | 22 | 24 | 22 | 24 |
| Power(KW) | 0.37 | 0.75 | 1.1 | 1.5 | ||||||
| Horsepower(HP) | 0.5 | 1 | 1.5 | 2 | ||||||
| voltage(V) | 220-240/380-460 | |||||||||
| Frequency(HZ) | 50/60 | |||||||||
| Air volume(m³/min) | 4000 | 5000 | 7000 | 10000 | 11000 | 11500 | 12000 | 13000 | 14000 | 15000 |
| Rotating speed(rpm) | 120 | 100 | 90 | 80 | 70 | 60 | 55 | 50 | 55 | 50 |
| Number of leaves(Pcs) | 5/6 | |||||||||
| Noise(dB) | 38 | |||||||||
| Motor weight(kg) | 18 | 18 | 25 | 25 | 48 | 48 | 48 | 48 | 58 | 58 |
| Ceiling fan weight(kg) | 35 | 38 | 46 | 49 | 99 | 103 | 107 | 111 | 118 | 122 |
| Effective area(m²) | 150 | 230 | 256 | 300 | 500 | 600 | 650 | 700 | 750 | 800 |
| Coverage area(m²) | 250 | 380 | 450 | 500 | 900 | 1000 | 1300 | 1500 | 1600 | 1700 |
• The motor of the ceiling fan is CSA certified.
• Delivery time: Within 20 days after receipt of payment by TT.
• Warranty: Permanent magnet motor warranty period of 3 years; controller warranty period of 18 months.
